Description

Description:

AP Armaflex Sheet and Roll Insulation is the original closed cell, fiber-free elastomeric foam and the world’s most recognized brand in flexible mechanical insulation.

Uses:

The recommended temperature usage range for AP Armaflex Sheet & Roll Insulation is -297°F to +220°F (-183°C to +105°C) according to method of application. With full adhesive coverage attachment, the surface to which it is applied may operate to a limit of 180°F (82°C). When used for pipe insulation with adhesive adhering seams and joints only, AP Armaflex Sheet can be applied to lines that will operate to a limit of 220°F (105°C). On cold systems, insulation thicknesses have been calculated to control condensation on the insulation outer surface, as shown in the table of thickness recommendations. AP Armaflex Sheet and Roll Insulation meets the energy code requirements of International Energy Conservation Code (IECC)and ASHRAE for R-Value 4.2 at 1? wall thickness and R-Value 8 at 2? wall thickness. Retards heat gain and controls condensation drip from chilled-water and refrigeration systems. Efficiently reduces heat flow on hot systems Acceptable in wall thicknesses through 2? (50mm) for use in air plenums and conforms to NFPA 90A and NFPA 90B requirements
